Wires for railway vehicles and trolley-busses are designed for internal and external wiring of railway vehicles and trolley-busses.
Wire models and their definitions shall correspond to the details given in the table below:
| Model | Definition | Primary operation area |
| PPSV | Wire with polyvinylchloride (PVC) insulation for railway vehicles | Hardwiring and limited-mobility mounting under exposure to lubricant oils and diesel fuel |
| PPSVVM | Wire with polyvinylchloride (PVC) insulation in PVC sheath for railway vehicles | Limited-mobility mounting, movable pantograph connection, hardwiring under exposure to lubricant oils and diesel fuel |
| PPSTVM | Wire withthermoelastoplast (TEP) insulation in PVC sheath for railway vehicles | Limited-mobility mounting, movable pantograph connection, hardwiring under exposure to lubricant oils and diesel fuel |
| PPSTVMng(A) | Wire withTEP insulation in PVC sheath for railway vehicles | Limited-mobility mounting, movable pantograph connection, hardwiring under exposure to lubricant oils and diesel fuel |
Rated conductor area range, numbers of conductors, rated voltage values for wires shallcorrespond to the details given in the table below:
| Model | Rated wire voltage, V | Number of conductors | Rated conductor area range, mm2 | ||
| Alternating current up to 400 Hz frequency | Direct current | ||||
| PPSV | 660 | 1000 | 1, 2* | from 0.5 to 6 | |
|
PPSVVM, PPSTVM, PPSTVMng(A) |
660 1000 1500 3000 4000 |
1000 1500 2500 4500 6000 |
1 |
from 1.0 to 300 |
|
| * Double-conductor wire representing the two single wires. | |||||
CONDUCTOR:copper, stranded.
INSULATION:for PPSV, PPSVVM models - PVC compound;
for PPSTVM, PPSTVMng(A) models - thermoelastoplast;
SHEATH:for PPSV, PPSVVM
models - PVC compound;
forППСТВМнг(А) model - fire-resistant PVC compound;
NUMBER OF CONDUCTORS:1
CONDUCTOR AREA, mm²:0.5-300
Wires are resistant to diesel fuel, rain effect, abrasion, dust, hoarfrost, folding, abrasion and pressing.
Operating temperatures range: from -40°Сto +70°С
Insulating resistance is not less than 100 MΩ.
Wires of PPSV, PPSVVM, PPSTM models do not spread combustion when single laid.
Model PPSTVMng(A) does not spread combustion when laid as harness.
Do not expose the wire to direct sunlight.
Factory cable length is not less than 100 m.
Cables operational life is not less than 30 years.
